Variant 1000kg Aluminium Ramp Pair 91003

VAR/91003

$560.00 inc GST

1000kg Ramp pair (2500mm x 260mm)

Suitable for machinery, vehicles and equipment

Load depends on axle distance. The axle distance is between the front and rear wheels.

1000kg Ramp pair (2500mm x 260mm)

Suitable for machinery, vehicles and equipment

Load depends on axle distance. The axle distance is between the front and rear wheels.

Load applies to 2-axle vehicle and 1 set of ramps.
Distribution of weight with a maximum of 2/3 on one axle. The axle with the highest load must always be at the top of the ramp when driving up and down.
REMEMBER to include the weight of the driver, fuel, equipment etc
Ramps must NEVER be used as a bridge/plank, i.e. without an approach angle

For load/drive-up, please see specifications.



Safety measures:

  • Always wear gloves when handling the ramps
  • Only use the ramps on stable and firm ground
  • Persons other than the user must keep an appropriate distance during use
  • Driving up and down the ramps may only be done under the supervision of another person.
  • Never use the ramps if there is visible damage
  • The ramps must rest on the trailer with the entire installation surface
  • The ramps must be attached to the trailer with bolts or similar.
  • Maximum permitted wheel width is ramp width minus 20 mm

Additional information

Brand

Load / Wheelbase >1200 mm

1000kg

Load / Wheelbase 750-1200 mm

800kg

Load / Wheelbase 500-750 mm

700kg

Max Load (Per Pair)

1000kg

Max Loading/Driving Height

72cm

Single Ramp Dimensions

2500 x 260 x 75mm
